A high performance semi-metallic gasket designed to be used for high temperature and high pressure.
Not easily affected by temperature changes. It demonstrates excellent sealing property under harsh conditions as in heat cycles caused by high and low temperatures
Tightening surface pressure control as in joint sheets is not required.
A spiral type gasket that uses graphite (expanded graphite material)tape as a filler material.
ข้อมูลสินค้า
Nominal Diameter (A) : 50
Nominal Diameter (B) : 2
Inner Diameter (mm) : 61
Outer Diameter (mm) : 104
Thickness (mm) : 4.5
Working Pressure (K) : 10/20
Working Temperature Range : -270degrees to 450degrees
วัสดุ
Seal Part : Expanded graphite filler material, SUS-based hoop material
Metal Protection Part : Inner and outer ring SS304
น้ำหนัก
115 g
การใช้งาน
From general-purpose piping to areas where a high temperature and high pressure flange is applied.
