Even though the size is small, the exhaust speed is higher.
Compact size ideal for incorporating into a device.
With the magnet coupling structure, no oil leaks from the shaft seal and a long service life has been realized.
By being equipped with a back-flow prevention valve directly under the intake pipe, the inside of the pump is automatically opened to the atmosphere when stopping.
Corresponds to diversification of power cords by the inlet of the power cord insertion port.
By being equipped with a forced oiling mechanism, the exhaust speed becomes stable.
Operable from the atmospheric pressure.
ข้อมูลสินค้า
Displacement Speed (L/min) 50/60Hz : 100/120
Ultimate Pressure (Pa) : 0.67
Inlet Caliber : KF-25
Power (V) : Single Phase 100V
Total Width x Total Length x Total Height (mm) : 150 x 413.5 x 234.5
With thermal protector
Working oil : R-2
2-stage exhaust system
CE marking self-declaration product
TUU, CTUVUS certified product
Can be individually customized for a special power supply voltage
น้ำหนัก
22.00 kg
การใช้งาน
For physicochemical experiments, for analytical instruments, laser application equipment.
Vacuum exhaust device, back of the electron microscope.
