An optimal system can be structured with free designs that suit the place of installation and the situation of the work involved.
Supports setups where the traveling rails are not parallel. (Installation to match the form of the building is possible.)
A curved traveling rail can also be installed. (supports non-linear tasks)
As commercially available steel H-beams (or I-beams) are used as the rail, the system is extremely low cost and can even be easily installed using existing ceiling joists. (It can also be moved after installation.)
The free crane moves lightly and smoothly and can be combined with an electric chain hoist, etc. to realize three-dimensional and simultaneous operation.
ข้อมูลสินค้า
Rated Load (t) : 0.25
Applicable Rail Width (mm) : 50, 75
Lifting height : Any
น้ำหนัก
6.40 kg
คำเตือน
Installing fixed support hangers with each other or installing free support hangers with each other is extremely dangerous. Be sure to install and use the fixed support hanger and free support hanger as a set.
