Pressure gauge structured to convey elastic deformation (movement) of Bourdon tube to the pointer. Since it has a simple structure, it is easy to handle.
JIS B 7505-1 standard product.
ข้อมูลสินค้า
Pressure Range (MPa) : 0.0 to 4.00
Min Scale (MPa) : 0.100
Accuracy : ±1.6% FS
Case Shape : A
Size : 75mm
Connection Size : G3/8B
วัสดุ
Bourdon Pipe : Brass, Pressure Range 6MPa or more is Stainless Steel (SUS 316)
Stock : Brass
น้ำหนัก
300 g
คำเตือน
Please confirm the screw size, thread shape (G thread or R thread), Pressure Range (MPa) then place an order.
