When placing/removing stored items, the rack is locked automatically at the fixed position (during storage and full stroke), and can be unlocked with a single operation.
Safe because it is equipped with a mechanism that prevents multiple drawers from being pulled out.
New strut with 75mm width specification and high rigidity, so the effective internal width is bigger.
At full stroke, it is possible to place/remove items at the back.
ข้อมูลสินค้า
Equal Load Capacity (t/stage) : 1
W x D x H (mm) : 1458 x 1550 x 2107
Fixed Shelf : 1
Number of Shelf Stages Sliding Shelf : 3
Fixed Shelf : 1374 x 907.4
Shelf Dimension (mm) Sliding Shelf : 1160 x 900
Main Body Specification : Single Type
Stroke (mm) : 800
Max Load Weight (t/piece) : 4
Assembly Type
Body color : Neo gray
Shelf Board Adjustable Pitch : 50mm
วัสดุ
Steel
อุปกรณ์ในกล่อง
Stand alone type : Screw anchor (M12 x 90)x 6, truss base x 2
Connected type : Screw anchor (M12 x 90)x 3, truss base x 1
น้ำหนัก
347.00 kg
การใช้งาน
For keeping and storing molding die and heavy items using a crane.
คำเตือน
Be sure to anchor it (M12 x 90 screw anchors are provided as a standard feature).
Be sure to use the truss base (standard specification).
TRUSCO
