When placing/removing stored items, the rack is locked automatically at the fixed position (during storage and full stroke), and can be unlocked with a single operation.
Safe because it is equipped with a mechanism that prevents multiple drawers from being pulled out.
New strut with 75mm width specification and high rigidity, so the effective internal width is bigger.
ข้อมูลสินค้า
Equal Load Capacity (t/stage) : 1
W x D x H (mm) : 1458 x 1050 x 2107
Fixed Shelf : 1
Number of Shelf Stages Sliding Shelf : 3
Fixed Shelf : 1374 x 907.4
Shelf Dimension (mm) Sliding Shelf : 1160 x 900
Main Body Specification : Connected Type
Stroke (mm) : 500
Max Load Weight (t/piece) : 4
Assembly Type
Body color : Neo gray
Shelf Board Adjustable Pitch : 50mm
วัสดุ
Steel
อุปกรณ์ในกล่อง
Stand alone type : Screw anchor (M12 x 90)x 8, truss base x 2
Connected type : Screw anchor (M12 x 90)x 4, truss base x 1
น้ำหนัก
250.00 kg
การใช้งาน
For keeping and storing molding die and heavy items using a crane.
คำเตือน
Be sure to anchor it (M12 x 90 screw anchors are provided as a standard feature).
Be sure to use the truss base (standard specification).
