There are only 2 or 3 threads at the entrance and as the external thread is screwed in (pushed in), the product digs into the threads and fastens it.
Regardless of the pitch on the external thread side, it is used as a replacement for a lost nut. (The one for M3 can also be used for the 1/8 inch size.)
As a nut that can be fastened without tools, it can be turned by hand or it can be fastened by being pushed in.
It can also be used as a protective cap for a hexagon nut that has been fastened, and since it is strong to vibrations, it can be used as a component to prevent the nut from falling loose.
Stainless steel and weight reduction of iron nut supported.
ข้อมูลสินค้า
Color : Black
Outer Diameter (mm) : 20.0
Knob Height (mm) : 10.0
Screw Diameter : M4
Effective Screw Depth (top part only) (mm) : 6.2
วัสดุ
Elastomer resin
น้ำหนัก
4 g
คำเตือน
Please take note that the guaranteed load is lower than that of metal nut.
MITSUBOSHI
