The alarm function of the control unit detects chamber temperature overheat, heater disconnection, triac short-circuit, abnormal temperature sensor abnormality, and low liquid level, and forcefully shuts down the heater and stirrer.
The power supply is equipped with an electric leakage breaker.
Can set auto start or auto stop timer (MAX 99 hours 59 minutes).
ข้อมูลสินค้า
Outer Dimension (mm) W x D x H : 640 x 380 x 500
Chamber Inner Dimension (mm) W x D x H : 440 x 300 x 300
Capacity (L) : 36
Temperature Range (°C) : 40 to 200
Power (V) : Single Phase 100
Temperature stability : ±0.05°C
Temperature Control : Digital Temperature Indicating Controller PID Control System
Heater : Sheath wire type 2kW
Stirrer : Vertical propeller agitator type 22W capacitor motor
Safety Equipment : Electric Leakage Breaker/Temperature Sensor in the Chamber/Self-diagnosis Function (heater disconnection, low water level, abnormal temperature sensor, triac short)
Timer : Operation with auto start or auto stop timer (MAX 99 hours 59 minutes)
