Ball screw type dry cylinder with high power transmission efficiency is adopted. (max. consecutive use : 100,000 times, vertical movement : 80 times/h)
There is no inertia at the time of ascending/descending stop, realizing smooth lifting and stopping.
Maintenance free by grease lubrication.
Low noise (62dB).
ข้อมูลสินค้า
Equal Load (kg) : 200
Table Dimension (mm) W x L : 500 x 800
Table Height (mm) : 250 to 1220
50Hz : 28/28
Rise/Fall Time (sec) 60Hz : 24/24
Motor Output (kW) : 0.2
Lift System : Electric Ball Screw Type
Power supply : Three phase 200V
Power cord : 4m
Operation Method : Foot Switch (cord length : 2m)
Unit : Built-in Type
Max. frequency of use : 80 times/h
น้ำหนัก
103.00 kg
การใช้งาน
Lifts as luggage lift and as a working table.
คำเตือน
Set the allowable weight when transferring the work to the arrow A 1/4ロB 1/2 of the main body photo.
Exceeding the max. use frequency may cause failures.
TRUSCO
