Horizontal slide type enabling to effectively use space.
Optimal to install on the chuck panel.
It is small and lightweight type and its body height is low, so it is suitable for mounting on automatic machines. It does not disturb the operation of the chuck panel even when removing the workpiece.
ข้อมูลสินค้า
Iron Wire : 1.0
Copper Wire : 1.6
Cutting Performance (mm) ABS Resin : 3.0
Pressure (N) : 343
Air Consumption ([[CM3]]/times) : 48
Working Air Pressure (MPa) : 0.4 to 0.5
W x D x H (mm) : 23 x 75.9 x 47.6
Mounting Hole (A x B) : 15 x 25
น้ำหนัก
155 g
การใช้งาน
Various gate cutting related to the ejector at resin molding factory.
