Insulated coating is preset in the cylinder part of the terminal.
Shape of insulator : The TME type has an electric wire insertion guide (funnel type)inside the insulted coating part. The core wire can be smoothly inserted to the cylinder part along the guide with the coating being stripped without needing to twist the core wire.
ข้อมูลสินค้า
Stranded Wire ([[MM2]]) : 2.63 to 4.60
Electrical Wire Tying Range AWG : 12
Color : Yellow
Outer Dimensions (mm) : 9.6
Stud Diameter (mm) : 5.3
Total Length (mm) : 28.0
Internal Dimensions (mm) : 6.3
JIS Standard Product : x
Single wire incompatible
วัสดุ
Terminal : Oxygen-free copper (electro tin plating)
Sleeve : Oxygen-free copper tube (electro tin plating)
NICHIFU
