High-precision speed drilling of C-type steel channel is possible.
The unique 3-angle cutting edge provides quick and steady drilling with a long life.
Can be attached/removed easily with a spanner.
ข้อมูลสินค้า
Cutting Diameter (mm) : 13.5
Max Processed Sheet Thickness (mm) : 6
Compatible electric motor : Drilling machine for channel steel, desktop drilling machine, electric drill (*Use dedicated chuck when not using a drilling machine for channel steel.)
Compatible model : HITACHI KOKI (BH18SA, BH18), NITTO KOHKI (AMT-18, AMW-22, AML-22)
HITACHI and NITTO type screw : 3/8-24UNF
Spanner hook : 12mm (17mm for 22.0mm caliber)
วัสดุ
Blade Part : Carbide Tip
น้ำหนัก
10 g
การใช้งาน
Work material : Steel channel (up to 6mm), angle steel.
