Uniquely developed power control and the air inlet for air cooling suppresses heat generation, making it possible to use it continuously for a long time.
Also used in machining scenes of aircraft material.
ข้อมูลสินค้า
Oscillation Frequency (kHz) : 40
Oscillator Input (V) 50/60Hz : AC200
Oscillator rated current (A) : 1.5
Oscillator Weight (kg) : 4.6
Electricity Consumption (VA) : 300
Handpiece Cord Length (m) : 5
Maximum output : 100W
Oscillator dimensions : W230 x D232 x H144mm
Frequency adjustment : Automatic tracking type
Power supply : Single‐phase current 200V 50/60Hz
Output adjustment : Stepless continuous variable
Vibrator dimensions : φ10/φ30 x L139.5mm
Vibrating Element : PZT Electrostrictive Oscillator
วัสดุ
Titanium Alloy (blade retaining part)
Case : SUS303
อุปกรณ์ในกล่อง
Replacement Blade
Automatic machine connection plug
น้ำหนัก
5.00 kg
คำเตือน
The setting of the oscillator varies depending on the vibrator and blade used.
Please contact us if you want to change the tool to use.
Please supply cooling air when making continuous use.
