2-point fixation distributes the load, ensuring effective load distribution in the base material to be welded too.
A V class (grade 100)is used to increase the lifting strength (grade 80 for 8ton and 15ton).
Forged load rings are DIN5691 compliant and magnetic particle tested.
A patented spacer functions as a gap filling material required for root running (about 3mm).
For the location of welding seams (HV penetrating type), the DIN18800 requirements are met and seams are completely shielded. A corrosion layer is unlikely to develop, enabling its use outdoors.
ข้อมูลสินค้า
Basic Working Load (t) : 31.5
B : 373
D : 78
C : 130
A : 160
F : 42
E : 178
Dimension (mm) G : 195
วัสดุ
Nickel Chrome Molybdenum Steel
Welding compatible material St52.3 (1.0570)forged product
น้ำหนัก
15.60 kg
การใช้งาน
Used for molding dies, precision/machine tools, and lifting heavy objects.
RUD
