Enables remote monitoring of trouble information (clogging of pipes, nor grease remaining, etc.)with a PLC systm.
Automatic lubrication is possible with an ON/OFF program of PLC signals.
Equipped with warning functions of alarms and buzzers when an error occurs with lubrication. (Purchase of PLC/DC converter and rotating warning light required separately.)
ข้อมูลสินค้า
Grease Capacity (cc) : 60
Lubrication cycle : 0.34cc x 1 to 6 times
H x W (mm) : 181 x φ91
Working environment temperature : -20 to 60°C
Output current : Max 1A
PLC DC12V/DC24V
Mounting screw dimensions : PT3/8
Multi-oiling for up to a maximum of 8 openings and piping can be installed for a maximum of 6m (when using grease #1)
Lubrication with 6 mode settings using PLC programs for the lubrication cycle (*The 6 modes are modes for discharge 6 times consecutively)
Working pressure : Normal 30kgf/[[CM2]] (max 60kgf/[[CM2]])
Power supply voltage : 9 to 36V DC only (no internal battery)
PULSARLUBE
