Can be used in combination with sensor and sticker according to applications. (leak water can not be detected by only sensors).
Water leak alarm will be generated when water reaches the installed water leak sensor. (guard lamp (per line), Buzzer, No-Voltage Contact Signal Output (batch and per line))
Detection sensitivity can be adjusted according to the sensor to be used and the fluid or liquid to be detected.
With self-diagnostic function that checks sensor disconnection and the detection line system. (WRNA, WRM8, WL-AD-2002-A)
Water leak alarm will be generated when water reaches the installed water leak sensor.
Detection sensitivity can be adjusted according to the sensor to be used and the fluid or liquid to be detected.
Constantly internally monitors the leakage detection accuracy and issues an error warning when there is an error.
ข้อมูลสินค้า
Working Temperature Range (°C) : -15 to 45
Number of Detection Points : 12
Power supply : AC100V
W x D x H : 250 x 90 x 300mm
Applicable sensor : B-3P, S-1F, S-1FP, PS-1R
External output : water leakage individual output (no voltage a contact), water leakage batch output (no voltage c contact), system error (sensor broken wire error, water leakage detection accuracy error)batch output (no voltage c contact)
อุปกรณ์ในกล่อง
Termination Kit : TR820 (accessory)
น้ำหนัก
4.00 kg
การใช้งาน
Refueling rooms, around air conditioners, under piping, etc. (buildings, factories, and condominiums, etc.)
