Detects metallic foreign objects in the production line with high sensitivity and contributes to provide safe and secure commodity.
7-inch colored touch panel. (equipped with voice guidance support function)
Video can be imported from USB memory.
High sensitivity detection : sensitivity setting is easily adjustable (Usually about 3 adjustments are required). In addition, phase tracking function enables you to track the phase variation of item in order to minimize the phase of item.
Discrete package item (optoelectronic sensor activation)mode, Discrete package item (optoelectronic sensor deactivation)mode, consecutive item mode and missing item mode are selectable from the touch panel.
ข้อมูลสินค้า
W x D x H (mm) : 800 x 727 x 1114 to 1264
Sensor head opening dimension : W450 x H170mm (passing height 150mm)
Detecting sensitivity : Fe : φ0.5mm, SUS : φ1.0mm
Conveyor belt width : 350mm
Conveyor overall length : 800mm
Installation/adjustment fee and shipping fee are separately charged.
Prior to delivery, preliminary discussion about product specifications is required.
A&D
