Oil mist is not collected through a filter so there is low air volume reduction due to clogging and performance can be maintained for long hours.
The enlargement of inspection door improved ease of maintenance significantly including the removal of collection disc and cleaning of the interior.
The suction port can be installed at the top left or right according to the installation location. (Top is standard.)
Right-hand or left-hand inspection door can be chosen. (Left-hand is standard.)
Since the collection disc can be cleaned and used repeatedly it is an environmentally friendly product.
ข้อมูลสินค้า
Power (V) : Three Phase 200
Output (kW) : 1.50
Air Volume ([[M3]]/min) (50/60Hz) : 13.0/15.0
Main Body Dimension (mm)W x D x H : 550 x 604 x 700
Mounting Dimension (mm) : 450 x 520
Inlet Diameter (mm) : 148
Standard Electric Consumption Rate : 20.25 yen/h
Collection efficiency : 99.9% (mass ratio of filter paper)
Removal type : Collection due to centrifugation and inertial impaction (filterless)
Applicable mist : Oil-based mist (flash point of 70°C or more)and water soluble oil mist can be used at the same time. (However it may not be usable depending on the oil mist generated.)
MIDORI ANZEN
