SANKO TECHNO

AX-M10

ALC Anchor AX Type (30 Set)

฿81
฿112
แบรนด์ SANKO TECHNO
รหัสสินค้า AX-M10
รหัสบาร์โค้ด 4996620240109
รหัสสั่งซื้อ 376-5091
สต็อกในไทย0
สต็อกในญี่ปุ่น90
กำหนดการจัดส่ง
ไม่เกิน 90 ชิ้น : 9 วันทำการ
91 ชิ้นขึ้นไป : โปรดติดต่อเจ้าหน้าที่
วิธีการนำเข้า ทางแอร์
ซัพพลายเออร์ TRUSCO JP
  • Expansion part opens upward and downward for strong fixation.
  • Tightening work does not damage the ALC panel.
  • Reliable construction management is possible when rotated 10 times.
  • Two wings increase shearing force and prevent co-rotation during construction.
ข้อมูลสินค้า
  • Nominal Designation of Thread : M10
  • Outer Diameter (mm) : 16.5
  • Total Length (mm) : 72
  • Punching Depth (mm) : 80
  • Buried Depth (mm) : 72
  • Drill Diameter (mm) : 16.5
  • Maximum Tensile Load (kN) : 3.6
  • Rotation number : 10 times
  • Construction bolt length (mm) : 30 or more
  • Packaged in a box
วัสดุ
  • Steel (expansion part)
  • Surface treatment : Trivalent chromate treatment
น้ำหนัก 43.9 g
การใช้งาน
  • For ALC panels.
  • For installation of light fixtures, exhaust ports, window grates, etc.
  • คำเตือน
    • The maximum tensile load is the data at ALC 100mm thick panel compressive strength Fc4N/[[MM2]].
    ประเทศที่ผลิต Japan
    เว็บของ Supplier SANKO TECHNO AX-M10
    หม่วดหมู่แบรนด์ SANKO TECHNO
    หม่วดหมู่สินค้า สกรู / ลูกล้อ / อุปกรณ์ติดตั้ง อุปกรณ์ยึดติด พุก ALC พุก ALC
