ASOH

AS-1011R

Acheck

฿723
฿1,002
แบรนด์ ASOH
รหัสสินค้า AS-1011R
รหัสบาร์โค้ด 4560130565061
รหัสสั่งซื้อ 796-2568
สต็อกในไทย0
สต็อกในญี่ปุ่น0
กำหนดการจัดส่ง โปรดติดต่อเจ้าหน้าที่
ผู้นำเข้า
วิธีการนำเข้า ทางแอร์
ซัพพลายเออร์ TRUSCO JP
  • Because the check valve body is a dual screw type, space for piping can be saved.
  • There is no leaking in relation to the check pressure because it is of a simple poppet structure.
  • Piping can be connected regardless of whether it is vertical or lateral.
ข้อมูลสินค้า
  • Effective Area ([[MM2]]) : 5.3
  • Fixed throttle diameter (mm) : 3.7
  • Connection Port Diameter : Rc1/8
  • Length between opposite sides of hexagon (mm) : 14
  • Total Length (mm) : 35
  • Working fluid : Air, water
  • Working temperature : 0 to 100°C
  • Max working pressure : 2.0MPa
  • Cracking pressure : 0.007MPa
  • O-ring : Fluorine rubber
วัสดุ
  • Main body : Brass (C3604BD, cd75PPM or less) + nickel plating
น้ำหนัก 38 g
ประเทศที่ผลิต Japan
เว็บของ Supplier ASOH AS-1011R
หม่วดหมู่แบรนด์ ASOH
หม่วดหมู่สินค้า อุปกรณ์นิวเมติกส์ อุปกรณ์นิวเมติก / อุปกรณ์ไฮดรอลิก วาล์วระบายอากาศ เช็ควาล์ว
